STREAMBUILDER
LIVE video Transcoding and Streaming software Input UDP, RTMP, MPEG-TS or SDI and stream HLS and DASH to any device!
- Input formats
UDP Multicast (igmp v2)
MPEG-2 TS
SPTS
MPTS
HLS
RTMP
SDI - Input codecs
avc/h264 high profile
mpeg2 video
MPEG1 Audio
AC3 Audio
avc/h264 main profile
avc/h264 baseline
hevc/h.265 main profile
- Transcoding parameters
avc/h264 high profile
avc/h264 main profile
Resolution adjustment
Bitrate (change/select)
GOP adjustment
CABAC adjustment
B frames adjustment (number of B-frames, B frames as reference)
Transcoding buffer size
Minimal L-frames interval
Quantization parameters (Adaptive Quantization, Spatial AQ and etc.)
Deinterlacer
Cropping
hevc/h.265 main profile - General
requirements
Quick Sync and GPU powered encoding
CPU: x86 Intel CPU i7/Xeon
GPU: Quadro, Tesla NVIDIA cards etc. RAM: minimum 8 Gb, recommended 32 Gb
For each output stream consider:
4GB RAM for 1080p → 1080p, 720p, 480p, 360p, 240p
3GB RAM for 1080p → 1080p
1.5GB RAM for 576p → 576p, 360p, 240p
HDD or SSD: 500 Mb for Streambuilder software consider some space for log files and output HLS, DASH
Following OS are supported: Ubuntu 20/22/24 LTS
- Audio transcoding parameters
AAC-LC
AAC-HE
Dolby Digital (AC3)
Multiple audio tracks transcoding for each video stream - Output transport
UDP Multicast (igmp v2)
MPEG-2 TS
SPTS
HLS
DASH - Extra features
SCTE-35 marks insertion into TS stream
Subtitles transcoding support (DVB and teletext subtitles, СС PID USER private, CC PID Teletext) - MPEG2 TS stream features
PID editing
SID editing
Program Name editing
~
Custom user cases
Ensures high availability by reserving N+M servers, with failover control managed by an external watchdog that monitors the presence of chunks/manifests.
A business logic service that places SCTE-35 markers in the output stream to manage advertising and content switching.
Allows replacement content insertion based on:
• SCTE-35 markers in the input stream.
• External commands via API or scripts.
• Fixed schedules with specific start times and durations.
• DTMF markers in audio tracks.
• SCTE-35 markers in the input stream.
• External commands via API or scripts.
• Fixed schedules with specific start times and durations.
• DTMF markers in audio tracks.
• Embeds logos, including graphics and text (e.g., age restrictions).
• Allows scheduled toggling of logo embedding.
• Allows scheduled toggling of logo embedding.
• Embeds subtitles directly into the video (hard embedding).
• Supports DVB Subtitles and WebVTT formats.
• Supports DVB Subtitles and WebVTT formats.
Enables recording of live streams for archival or playback purposes.
Automatically creates preview images (thumbnails) from live streams.
Secures content with multiple DRM technologies: FairPlay, PlayReady, Widevine, Verimatrix, and AES-128 encryption.
• Blackouts based on a schedule.
• Blackouts triggered by DTMF markers.
• Blackouts triggered by DTMF markers.
Inserts advertisements or alternate content triggered by SCTE-35 markers.
Enables unlimited replication of streams for wider distribution.
~
